Box Feeder and Brick Machine Feeder for Streamlined Brick Manufacturing Equipment

Applicable Industries : Energy & Mining

Showroom Location : None

Condition : New

Type : Other, Box feeder machine

Brick Raw Material : FLY ASH

Processing : Brick Molding Machine

Method : Autoclaved Aerated Concrete

Automatic : Yes

Production Capacity (Pieces/8 hours) : 20-40M3/H

Place of Origin : Henan, China

Brand Name : SINOLION box feeder

Voltage : 220V/380V/440V

Dimension(L*W*H) : 3680*1300*960mm

Warranty : 1 Year, 1 year

Key Selling Points : evenly feeder

Brick size : Other

Machinery Test Report : Provided

Video outgoing-inspection : Provided

Marketing Type : New Product 2020

Warranty of core components : 1.5 years

Core Components : Motor

Weight (KG) : 1600 kg

Product Name : Box feeder machine and brick machine feeding machine production line

Keywords : Box feeder machine

After-sales Service Provided : Engineers available to service machinery overseas

Name : Box feeder

Raw material : high quality steel

Color : Optional

Products : 20-40m3/h

Model : JB200

Certification : CE/ISO9001

Price : $1,500.00/sets >=1 sets

MOQ : 1 unit

Contact Now

Product Details

Best sell box feeder machine and brick machine feeding machine of production line

Box feeder machine supports the use of brick machine, briuqette machine,ball mill etc ,they are used for quantitative and definite proportion shipping of raw materials, the tape conveyor is used to feed material for briquette machine, brick machine and ball mill etc.

It is a necessary feeding equipments of briquette, brick production line

Product Introduction
Box Feeder and Brick Machine Feeder for Streamlined Brick Manufacturing Equipment

Features of box feeder machine / box feeding equipment

The box feeder machine has Firm structure , simple installation ,reliable and safe operation , small labor intensity and so on, it can be matched with special platform balances for weighing, the quantitative and definite proportion formula is accurate, so it is a essential equipment for raw material processing workshop of ceramics factory.


Box Feeder and Brick Machine Feeder for Streamlined Brick Manufacturing Equipment

Working principle of box feeder machine/ box feeding equipment

The main motor of box feeder machine / box feeding equipment runs through the three root type A triangle leather belt. The cycloidal pinwheel reducer and a pair of inclinded gear will torque to active sprocket. The sprocket drive chain and the carrier board device run with the speed of v=1.14m/min . Raw materials on the carrier board move forward together with the carrier board and the load weight can be adjusted by the gate. The raw materials fall down to the hopper (made by the user) through the crusher then feed the next machine through the belt conveyor.
Product Parameters
Model
Capacity(M3/H)
Power (kw)
Overalsize (mm)
JB200
20-25
22
3680*1300*960
JB250
25-28
22
4180*1300*960
JB300
30-35
30
4680*1300*960
JB350
30-40
45
5180*1300*960
Working site picture
Box Feeder and Brick Machine Feeder for Streamlined Brick Manufacturing Equipment

Box feeder machine used in briquette production line

Box Feeder and Brick Machine Feeder for Streamlined Brick Manufacturing Equipment

Box feeder machine used in brick making line

Product Packing
Box Feeder and Brick Machine Feeder for Streamlined Brick Manufacturing Equipment
Box Feeder and Brick Machine Feeder for Streamlined Brick Manufacturing Equipment

Box feeder machine / box feeding equipment loading No.1


Box feeder machine / box feeding equipments loading
