Double Screen Gravity Separator Gold Trommel Washing Plant Multiple Material Cleaning

Name: Double Screen Gravity Separator Gold Trommel Washing Plant Multiple Material Cleaning
Brand: Sinolion
Price: 7 USD

Quality Double Screen Gravity Separator Gold Trommel Washing Plant Multiple Material Cleaning for sale

Applicable Industries : Building Material Shops, Manufacturing Plant, Construction works , Energy & Mining, Other

Showroom Location : Canada, United States

Condition : New

Type : Gravity Separator

Production Capacity : 90%

Place of Origin : Henan, China

Brand Name : Sinolion

Voltage : 220V/380V/415V/480V

Dimension(L*W*H) : 3200*1400*1900

Weight : 1900 KG

Warranty : 1 Year

Marketing Type : Hot Product 2023, Hot Product 2023

Machinery Test Report : Provided

Video outgoing-inspection : Provided

Warranty of core components : 1 Year

Core Components : Bearing, Motor, Engine, Gearbox

Key Selling Points : High Rigidity

Installation : supply manual to guide user

Customizable : logo / packing / graphic

Advantege : obvious gold-selected effect

Double screen : Multiple material output

Packaging Details : All products will be processed to be rustproof and moisture proof before delivery.
20GP container or 40GP container
Equipment is packed with plastic wrap or steel case, depends on machine weight.
Motor is packed with steel case or wooden case.

Port : Qingdao, Tianjin, Lianyungang, Shanghai Guangzhou( as client request)

Supply Ability : 50 Set/Sets per Month gold trommel screening plant

Price : $7,750.00/sets 1-2 sets

MOQ : 1 unit

Contact Now

Product Description

^{Our equipment is called gold mobile trommel screen, which is used to collect gold from placer gold、alluvial gold and rock gold .}Gold mobile trommel screen is composed of feed hopper, drum, motor, water pump, reducer, wheel roller, transmission device (optional parts: gasoline engine and belt conveyor).

^{It is mainly used in the processing and collection of alluvial gold and placer gold. Its advantages include flexible movement, small size and high screening efficiency.}

Double Screen Gravity Separator Gold Trommel Washing Plant Multiple Material Cleaning

Sluice Box

Gold sluice box is lined with a professional sticky gold blanket made of polyethylene non-woven bottom, which has strong catching ability, high recovery rate, and is also effective for fine-grained gold. And it has the advantages of favorable price, simple structure and easy operation.

Double Screen

The drum part is made of round steel and
manganese wire, and the outer screen is made of manganese wire.which is strong and
durable. The design of the double-layer screen improves the screening efficiency on the one hand. and can screen materials of three specifications, On the other hand. it protects and improves the service life of the screen.

Trommel Screen

The drum part is made of round steel and manganese wire, and also has three outlets.it improves the screening efficiency of materials, the maximum product under the sieve is 100mm. the middle is 10-50 mm, the thinnest can reach 3 mm.

Technical Parameters

Model	Capacity (t/h)	Power (kw)	Diameter (mm)	Length(mm)	Discharge(mm)	Input(mm)	Dimension (mm)
GMTS0519	5—10	1.5	500	1910	≤300	0—100	300010001800
GMTS1020	10—30	4	1000	2000	≤300	0—100	320014001900
GMTS1225	30—50	5.5	1200	2500	≤300	0—100	430016502220
GMTS1548	80—150	11	1500	4800	≤300	0—100	800022003600
GMTS1848	100—200	15	1800	4800	≤300	0—100	800022004000

Packing & Delivery

Wooden box packing or Container shipping.
