Dependable Mobile Gold Trommel Screen for River Mining Feeding Size Less than 300mm

Zhengzhou Sinolion Machinery Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Dependable Mobile Gold Trommel Screen for River Mining Feeding Size Less than 300mm

Applicable Industries : Manufacturing Plant, Farms, Energy & Mining

Showroom Location : United States, Australia

Condition : New

Type : Gravity Separator

Production Capacity : 98%

Place of Origin : Henan, China

Brand Name : Sinolion

Voltage : 380V/415V/440V( as client request)

Dimension(L*W*H) : As per different model

Weight : 2200 KG, 6.5-10T

Warranty : 24 months excluding spare parts

Marketing Type : New Product 2023

Machinery Test Report : Provided

Video outgoing-inspection : Provided

Warranty of core components : 1 Year

Core Components : Motor, Pump, Gear, PLC, Other

Key Selling Points : mobile gold washing trommel

Product name : Mobile stationary sand trommel screen for river gold mining equipment

Model : rotary trommel screen

Power : 5.5KW, 7.5KW, 11KW

Dimension : depends on model

Application : alluvial gold washing, diamond, rock, soil, river gold

Capacity : 30-150 tons per hour

Feeding size : less than 300mm

Discharge size : less than 6mm

Color : yellow, white, red, blue, gray( or as client request)

Packaging Details : All products will be processed to be rustproof and moisture proof before delivery.
20GP container or 40GP container
Equipment is packed with plastic wrap or steel case, depends on machine weight.
Motor is packed with steel case or wooden case.

Port : Qingdao, Tianjin, Lianyungang, Shanghai Guangzhou( as client request)

Supply Ability : 50 Set/Sets per Month gold trommel screening plant

Price : $4,080.00 - $24,000.00/sets

MOQ : 1 unit

Contact Now

Dependable Mobile Gold Trommel Screen for River Mining Feeding Size Less than 300mm
Dependable Mobile Gold Trommel Screen for River Mining Feeding Size Less than 300mm
Dependable Mobile Gold Trommel Screen for River Mining Feeding Size Less than 300mm
Mobile Stationary Sand Trommel Screen For River Gold Mining Equipment
Mobile Gold Mining Equipment Is Represented By Trommel Screen, Which Is Also Widely Used In Separation Technology. Its Working Principle Is To Control The Size Of Particle Size To Control The Separation Of Waste, Thus Improving The Separation Efficiency. The Advantages Of Small Trommel Screen Are Obvious, And It Is More Flexible And Convenient Than Large-scale Mobile Screen In Terms Of Movement. Trommel Screen Internal Equipment, The Main Roller Screen Shall Have Motor, Reducer, Roller Device, Frame, Seal Cover, Inlet And Outlet Composition. The Roller Device Is Tilted On The Rack And Passed Through The Drum Device. The Axles Are Connected Together To Drive The Drum Device To Rotate Around Its Axis.
Dependable Mobile Gold Trommel Screen for River Mining Feeding Size Less than 300mm
Dependable Mobile Gold Trommel Screen for River Mining Feeding Size Less than 300mm
Dependable Mobile Gold Trommel Screen for River Mining Feeding Size Less than 300mm
Dependable Mobile Gold Trommel Screen for River Mining Feeding Size Less than 300mm
Dependable Mobile Gold Trommel Screen for River Mining Feeding Size Less than 300mm

Structure and Principle

The Alluvial Gold Trommel Screen Machine Uses The Principle Of Gravity Separation, The Original Ore Through A Layer Of Screening And Classification Under The Impact Of Water Into The Agitation Sluice Chute For Next Step Coarse Separation, If There Is Capillary Gold In The Original Mine, Adding The Agitation Chute Fixed Chute In The Tail To Avoid Tails Running. If There Is Clay Mud In Original Ore, We Will Add Stirring In Front Of The Screen And Flushing Device In Screen Drum, So That The Unfavorable Factors Caused By High Mud Content Can Be Solved Well, And Can Be Adjusted According To Ore Body Condition And Site.
1. Input Of Raw Materials Raw Materials Inputted Through The Entrance Of The Hopper Will Be Pushed Into The Trommel Screen By The
Strong Water Pressure Of The Shower Equipped In The Hopper. 2. Selection And Cleaning Of Raw Materials Raw Materials Of The
Trommel Screen Will Be Cleaned And Selected By The Rotation Of Trommel Screen And By Watering Of The Shower Inside, Run Into The
Gold Dust Separate Panel. 3. Collecting Of Gold Dust Separated Soil And Sands With Lighter Specific Gravity Will Flow Away But
Gold Dusts With Greater Specific Gravity Will Be Staying In The Gathering Mat To Be Collected.

Dependable Mobile Gold Trommel Screen for River Mining Feeding Size Less than 300mm
Product Name
Gold Trommel Screen
Model
GMTS0519
GMTS1020
GMTS1225
GMTS1548
GMTS1848
Capacity (t/h)
5-10
10-30
30-50
80-150
100-200
Power(kw)
1.5
4
5.5
11
15
Diameter(mm)
500
1000
1200
1500
1800
Length(mm)
1910
2000
2500
4800
4800
