Alluvial Portable Diamond Mining Equipment Designed with KG Gravity Separator

Name: Alluvial Portable Diamond Mining Equipment Designed with KG Gravity Separator
Brand: sinolion
Price: 4 USD

Quality Alluvial Portable Diamond Mining Equipment Designed with KG Gravity Separator for sale

Applicable Industries : Energy & Mining

Showroom Location : Canada, Mexico, UAE, None

Condition : New

Type : Gravity Separator

Production Capacity : 98%

Place of Origin : China

Brand Name : sinolion

Voltage : 380v/415v/440v

Dimension(L*W*H) : depends on models

Weight : KG

Warranty : 1 Year

Marketing Type : New Product 2022

Machinery Test Report : Provided

Video outgoing-inspection : Provided

Warranty of core components : 1.5 years

Core Components : Motor

Key Selling Points : Automatic

Application : gold mining, gold mine

Power : 3-45KW

Screen material : steel bar, steel plate punch hole, steel wire woven, stainless steel

Dimension : according to capacity

Installation : supply manual to guide user

Capacity : 50-500 tons per hour

Feeding size : less than 300mm

Discharge size : as request

Color : yellow, white, red, blue, gray( or as client request)

After-sales Service Provided : Field installation, commissioning and training

Price : $4,080.00 - $17,900.00/sets

MOQ : 1 unit

Contact Now

Factory direct sale alluvial mine trommel alluvial portable diamond mining equipment

Placer gold machine, placer gold beneficiation machinery as a mining, recovery of sand gold heavy metal machine is currently used in the global scope of sand gold mining areas. They come in many sizes, but they are all designed and made with the aim of recycling gold.

The alluvial gold machine movement is very convenient and can be applied to a variety of terrain, terrain is soft sandy or hard rock, stone or more can be applied, and must also very convenient, can satisfy the development of mining while walking. This method has a good effect on a large range of sand gold mining areas, which can save more production costs and increase mining efficiency.

Gold washing trommel working principle::
1. Input of raw materials Raw materials inputted through the entrance of the hopper will be pushed into the trommel screen by the strong water pressure of the shower equipped in the hopper.

2. Selection and cleaning of raw materials Raw materials of the trommel screen will be cleaned and selected by the rotation of trommel screen and by watering of the shower inside, run into the gold dust separate panel.

3. Collecting of gold dust separated Soil and sands with lighter specific gravity will flow away but gold dusts with greater specific gravity will be staying in the gathering mat to be collected.

Alluvial Portable Diamond Mining Equipment Designed with KG Gravity Separator

technical parameters

SPECIFICATIONS OF PORTABLE MOBILE GOLD WASH TROMMEL
Model	GMTS-500x1910
Drum Diameter	500mm
Drum Length	1910 mm
Gearbox	WPS-100-20
Towing Hook	Include
Tires Size	165/70RB
Rubber Tires Quantity	4 pieces
Spray Pipe Diameter	42mm
Spray Pipe Material	Galvanized seamless pipe
Capacity	5-10 tons/hour
HONDA Gasoline Engine	Main Power:5.5HP Start method: Manual pull Gasoline load: 0.58L
Gold Chute	350*1500mm Angle adjustable 2-8°
Grizzly	Steel bard diameter 20mm Bar spacing 50mm Input hopper: 0.5m³
