Steel Plate Material Drum Screen Filter for Compost Processing and Versatile Screening

Name: Steel Plate Material Drum Screen Filter for Compost Processing and Versatile Screening
Brand: Sinolion
Price: 4 USD

Quality Steel Plate Material Drum Screen Filter for Compost Processing and Versatile Screening for sale

Applicable Industries : Energy & Mining

Showroom Location : Mexico

Video outgoing-inspection : Provided

Machinery Test Report : Provided

Marketing Type : New Product 2020

Warranty of core components : 1 Year

Core Components : Motor

Condition : New

Type : compost trommel screener

Application : topsoil, compost, solid, municipal soild waste, glass, mulch, organics, bark, MSW, municipal solid waste

Place of Origin : China

Brand Name : Sinolion

Voltage : 380V/415V/440V( as client request)

Dimension(L*W*H) : As per different model

Weight : 2200 KG

Warranty : 18 month excluding spare parts

Product name : High quality rotary compost sifter /drum screen filter for compost

Screen material : steel bar, steel plate, manganese steel wire woven, stainless steel

Power : 3-45KW

Dimension : 5600x2015x2010mm

Installation : supply manual to guide user

Capacity : 1-200 tons per hour

Feeding size : less than 300mm

Discharge size : less than 6mm or as request

Color : yellow, white, red, blue, gray( or as client request)

Price : $4,100.00 - $28,750.00/sets

MOQ : 1 unit

Contact Now

High quality rotary compost sifter /drum screen filter for compost

Shaftless trommel screen working principle:
Due to the turning and rolling of the material in the screen drum, the material stuck in the screen hole can be ejected to prevent the screen hole from being clogged. GTS series shaftless trommel screen machine mainly consists of motor, gearbox, screen drum, frame, sealing cover, inlet and outlet. The screen drum is mounted obliquely on the frame. The motor is coupled to the drum unit via a coupling through a reducer to drive the screen drum unit to rotate about its axis. After the material enters the screen drum, due to the tilting and rotation of drum screen, the material on the screen surface is turned over and rolled, so that the qualified material (the product under the sieve) is discharged through the screen, and the unqualified material (the product on the sieve) ) is discharged through the end of the screen drum.

Steel Plate Material Drum Screen Filter for Compost Processing and Versatile Screening

Application:munlcpal solid waste,construction waste,stone,compost,wood chips,sawdust,soil,coal,river sand,refractory materials,chemiacal,etc

Technical parameter of shaftless trommel screen

Model	Trommeldiameter (mm)	Trommel length (mm)	Capacity (m3/h)	motor power(KW)	Weight (Kg)	Dimensions (LWH)
MTS0818	800	1800	≤15	2.4	650	3.151.11.65
MTS1022	1000	2200	≤30	8.2	2750	4.31.92.45
MTS1230	1200	3000	≤60	10.6	3210	5.42.12.7
MTS1550	1500	5000	≤90	20	7900	9.42.22.9

Steel Plate Material Drum Screen Filter for Compost Processing and Versatile Screening

Steel Plate Material Drum Screen Filter for Compost Processing and Versatile Screening Images
